P8 Outdoor LED Display Module (320×160mm)
Pixel pitch: 8 mm
Recommended: Highway billboards, unipole advertising, building façade screens, large outdoor displays
Product specifications and description
Key Features
- - High-brightness SMD3535 LEDs ideal for direct sunlight conditions.
- - Perfect for large outdoor advertising such as unipoles and rooftops.
- - IP65 waterproof protection ensures all-weather outdoor operation.
- - High contrast & wide viewing angle for long-distance visibility.
- - Ideal choice for cost-effective large billboard projects.
- - UV-protected mask prevents sun damage and color fading.
- - Supports up to 7680 Hz refresh rate — smooth playback for video ads.
- - Stable 24/7 outdoor performance in Bangladesh weather.
- - Compatible with all standard outdoor 960×960 and 1280×960 cabinets.
- - Long lifespan with low maintenance requirements.
| Pixel Pitch | 8 mm |
| LED Type | SMD3535 (High-brightness outdoor) |
| Module Size | 320 × 160 mm |
| Module Resolution (W×H) | 40 × 20 pixels |
| Pixel Density | 15,625 dots/m² |
| Brightness | 6000 – 7500 cd/m² |
| Color Temperature | 2000K – 9500K adjustable |
| Viewing Angle (H/V) | 160° / 140° |
| Brightness Uniformity | = 97% |
| Contrast Ratio | 5000 : 1 |
| Refresh Rate | 1920 – 7680 Hz |
| Gray Scale | 14 – 16 bit |
| Driving Mode | 1/5 scan |
| Frame Frequency | 50 / 60 Hz |
| Max Power Consumption | 580 – 650 W/m² |
| Typical Power Consumption | 200 – 250 W/m² |
| Working Voltage | DC 5V |
| Input Voltage | AC 110 – 240 V, 50/60 Hz |
| IP Rating (Front/Back) | IP65 / IP54 |
| Operating Temperature | -20°C ~ +60°C |
| Operating Humidity | 10% – 90% (non-condensing) |
| Module Weight | 0.55 kg ± 0.03 |
| Module Thickness | 18 mm |
| Mask Type | UV-resistant outdoor mask |
| Maintenance | Front / Rear service (depends on cabinet) |
| Compatible Cabinet Sizes | 960×960 mm / 1280×960 mm outdoor cabinets / iron or die-cast cabinets |
| Control System | Compatible with NovaStar / Colorlight / Huidu / Linsn |
| Certifications | CE / ROHS / EMC / IP65 Outdoor Protection |
