P6.67 Outdoor LED Display Module (320×160mm)
Pixel pitch: 6.67 mm
Recommended: Unipole billboard, roadside LED display, rooftop screen, building façade, outdoor advertising
Product specifications and description
Key Features
- - High-brightness SMD2727 ensures clear visibility in direct sunlight.
- - Ideal for roadside LED billboards, unipoles & rooftop displays.
- - Strong waterproof IP65 front protection for all-weather operation.
- - High refresh rate (up to 7680 Hz) gives smooth video & animations.
- - Designed for 24/7 long-term commercial outdoor advertising.
- - UV-protected mask prevents fading under sunlight.
- - Wide 160° viewing angle for maximum visibility.
- - Stable performance in Bangladesh heat, rain & dust.
- - Cost-effective, durable and long-lifespan outdoor LED module.
- - Compatible with standard 960×960 & 1280×960 outdoor cabinets.
| Pixel Pitch | 6.67 mm |
| LED Type | SMD2727 (High-brightness outdoor LED) |
| Module Size | 320 × 160 mm |
| Module Resolution (W×H) | 48 × 24 pixels |
| Pixel Density | 22,500 dots/m² |
| Brightness | 5500 – 6500 cd/m² |
| Color Temperature | 2000K – 9500K adjustable |
| Viewing Angle (H/V) | 160° / 140° |
| Brightness Uniformity | = 97% |
| Contrast Ratio | 5000 : 1 |
| Refresh Rate | 1920 – 7680 Hz |
| Gray Scale | 14 – 16 bit |
| Driving Mode | 1/6 scan |
| Frame Frequency | 50 / 60 Hz |
| Max Power Consumption | 620 – 680 W/m² |
| Typical Power Consumption | 210 – 260 W/m² |
| Working Voltage | DC 5V |
| Input Voltage | AC 110 – 240 V, 50/60 Hz |
| IP Rating (Front/Back) | IP65 / IP54 |
| Operating Temperature | -20°C ~ +60°C |
| Operating Humidity | 10% – 90% (non-condensing) |
| Module Weight | 0.55 kg ± 0.03 |
| Module Thickness | 18 mm |
| Mask Type | UV-resistant outdoor mask |
| Maintenance | Front / Rear service (cabinet dependent) |
| Compatible Cabinet Sizes | 960×960 mm / 960×960 iron cabinet / 960×960 die-cast / 1280×960 outdoor cabinet |
| Control System | Compatible with NovaStar / Colorlight / Huidu / Linsn / LEDSet |
| Certifications | CE / ROHS / EMC / IP65 Outdoor Protection |
