P10 Outdoor LED Display Module (320×160mm)
Pixel pitch: 10 mm
Recommended: Highway billboards, unipole advertising, building rooftops, stadium perimeter displays, government outdoor signage
Product specifications and description
Key Features
- - High-brightness SMD3535 LEDs for clear visibility in direct sunlight.
- - Perfect for large billboards, unipoles, rooftops and stadium screens.
- - Robust IP65 waterproof design for all-weather outdoor use.
- - Very high durability with UV-resistant masks for long-term advertising.
- - Long-distance viewing optimized — ideal for highway and roadside ads.
- - High refresh rate ensures flicker-free video playback.
- - Most commonly used outdoor module for large-format LED billboards in Bangladesh.
- - Supports 24/7 continuous operation in tough outdoor conditions.
- - Easy maintenance with front/rear service options depending on cabinet.
- - Highly cost-effective option for government & commercial outdoor projects.
| Pixel Pitch | 10 mm |
| LED Type | SMD3535 (High-brightness outdoor) |
| Module Size | 320 × 160 mm |
| Module Resolution (W×H) | 32 × 16 pixels |
| Pixel Density | 10,000 dots/m² |
| Brightness | 6500 – 8000 cd/m² |
| Viewing Angle (H/V) | 160° / 140° |
| Color Temperature | 2000K – 9500K adjustable |
| Brightness Uniformity | = 95% |
| Contrast Ratio | 4500 : 1 |
| Refresh Rate | 1920 – 3840 Hz (up to 7680 Hz optional) |
| Gray Scale | 14 – 16 bit |
| Driving Method | 1/2 scan or 1/4 scan (module version dependent) |
| Max Power Consumption | 550 – 620 W/m² |
| Typical Power Consumption | 160 – 240 W/m² |
| Input Voltage | AC 110 – 240 V, 50/60 Hz |
| Working Voltage | DC 5V |
| Frame Frequency | 50 / 60 Hz |
| IP Rating (Front/Back) | IP65 / IP54 |
| Operating Temperature | -20°C ~ +60°C |
| Operating Humidity | 10% – 90% RH (non-condensing) |
| Module Weight | 0.55 kg ± 0.03 kg |
| Mask Type | Outdoor UV-resistant mask |
| Maintenance | Rear or front service (cabinet dependent) |
| Compatible Cabinet Sizes | 960×960 mm / 1280×960 mm / 960×640 mm — outdoor iron/aluminum cabinets |
| Control System | NovaStar / Colorlight / Huidu / Linsn / Xixun |
| Certifications | CE / ROHS / EMC / IP65 Outdoor Protection |
