Tripod Turnstile Gate Access Control System in Bangladesh
Recommended: Office entrance, factory gate, university campus, metro/bus terminal, stadium, bank, data center, secure lobby entrance
Product specifications and description
Key Features
- - Professional tripod turnstile gate system for office, factory and university in Bangladesh.
- - Supports RFID card, face recognition, fingerprint and QR reader for modern access control.
- - Bi-directional passage control – entry/exit direction fully configurable from access controller.
- - Fail-safe design: arm drop / free-passage mode during power failure or fire alarm.
- - Anti-tailgating, anti-reverse and illegal intrusion alarm increase security at main gate.
- - High throughput (25–40 persons/min) – suitable for busy corporate & campus entrances.
- - Dry-contact + Wiegand/RS485 interface – easy integration with existing attendance or access control system.
- - LED direction indicators and audio buzzer for easy guidance of visitors & staff.
- - Low power consumption & high MCBF life cycle – stable for 24/7 operation.
- - Ideal turnstile gate solution for Bangladesh access control projects and government tenders.
| Turnstile Type | Tripod three-arm turnstile (single lane) |
| Cabinet Material | SUS304 stainless steel |
| Cabinet Thickness | 1.2–1.5 mm (body) / 1.5–2.0 mm (top cover) |
| Passage Width | 510 mm (standard single person lane) |
| Arm Length | 500 mm (standard) |
| Direction | Single or bi-directional configurable |
| Throughput Capacity | 25–40 persons/min (card/face) / 15–20 persons/min (manual check) |
| Mechanism | Electro-mechanical, silent motor drive with damping |
| Fail Safe Mode | Drop-arm / free-passage on power failure (configurable with controller) |
| Working Voltage | DC 24 V (motor & control board) |
| Power Input | AC 100 – 240 V, 50/60 Hz (through SMPS power supply) |
| Control Interface | Dry contact / relay signal, RS485, Wiegand 26/34 (via controller) |
| Reader Support | RFID card, face recognition terminal, fingerprint reader, QR/Barcode scanner (optional) |
| Indicator | Bi-color LED direction indicator (arrow & cross) |
| Alarm Function | Illegal entry, tailgating, forced rotation, reverse entry (buzzer + light) |
| Operating Temperature | -20 °C ~ +60 °C |
| Operating Humidity | 5% – 90% RH (non-condensing) |
| IP Rating | IP44 (indoor) / IP54 (semi-outdoor with shed) |
| Housing Size (L×W×H) | 1200 × 280 × 980 mm (typical) |
| MCBF | 5,000,000 cycles (typical life cycle) |
| Integration | Compatible with ZKTeco / Hikvision / Dahua / Any Wiegand-based controller & face device |
| Certifications | CE / ROHS / EMC |
