Huidu HD VP820 LED Video Processor
Recommended: Concert LED walls, stage background, conference hall, auditorium, commercial LED screens
Product specifications and description
Key Features
- - Ultra-high 5.2 million pixel loading capacity — suitable for very large LED walls.
- - 8 Ethernet output ports for wide LED screen coverage.
- - Multiple video inputs: HDMI, DVI, VGA, CVBS, USB playback.
- - Professional PIP/POP function — dual-window display.
- - Seamless switching between input sources with zero delay.
- - Built-in high-quality image scaling engine.
- - Supports live events, stage screens, and commercial LED displays.
- - Supports HDMI audio and external audio input.
- - User-friendly control via software, LAN, USB & front panel.
- - Stable 24/7 operation for fixed installations & rental screens.
| Max Loading Capacity | 5.2 million pixels |
| Max Width | 8000 pixels |
| Max Height | 4096 pixels |
| Input Ports | HDMI × 2, DVI × 1, VGA × 1, CVBS × 2, USB Media Playback |
| Output Ports | 8 × Gigabit Ethernet ports |
| Video Input Formats | 1080p, 1080i, 720p, 576p, 480p, PAL, NTSC |
| Image Scaling | High-quality scaling with automatic resolution matching |
| Seamless Switching | Supported (Zero-latency switching) |
| PIP / POP | Picture-in-Picture + Picture-outside-Picture |
| Image Adjustment | Brightness, contrast, sharpness, RGB gain, color temperature |
| HDR Support | Optional (model dependent) |
| Audio Support | HDMI audio input + Separate audio input |
| Control Method | Front panel, USB, LAN, Huidu software, cloud control |
| Operating Voltage | AC 100–240V, 50/60 Hz |
| Operating Temperature | -20°C ~ 60°C |
| Recommended Applications | Concerts, live events, rental screens, large outdoor LED display, studio screens |
